Product Family
NetSure 5000 Series
Saved This Product to Your Dashboard
You just saved this product to your dashboard to view at a later time. You can easily remove the item from your dashboard when you no longer wish to have it saved.
Please login or create an account to save this for later
Best Suited For:
- Telecom
Product Family
NetSure 5000 Series
Best Suited For:
- Telecom
Specifications
|
NetSure 5100 582137100
|
||||||||
|---|---|---|---|---|---|---|---|---|
| 18-28.8kW / 1.5-19.2kW | 40-600A / 50-400A | -48 VDC, +24 VDC, -58 VDC | Single phase: 120VAC, 208VAC to 240VAC | Standard system | 8.75" | 19" or 23" | 23.04" with batteries | Up to 600 lbs. |
| See more product information | ||||||||
|
NetSure 5100 582137200
|
||||||||
| 2-7.2kW | 40-150A | -48VDC | Single phase: 120VAC, 208VAC to 240VAC | Integrated system | Up to 5.25" | 19" or 23" | 14.7" | Up to 48 lbs. |
| See more product information | ||||||||
|
NetSure 5100 58870530036
|
||||||||
| 8kW | Up to 160A | -48VDC | 120VAC, 208VAC, 240VAC | Bulk subrack | 1 RU | 19" or 23" rack | 15" | 25 lbs. |
| See more product information | ||||||||
|
NetSure 512 582137000 up to 525A
|
||||||||
| 18-28.8kW / 1.5-19.2kW | 40-600A / 50-400A | -48 VDC, +24 VDC, -58 VDC | Single phase: 208VAC to 240VAC | Two row system | 15.75" to 22.75" | 27" | 16" | Up to 550 lbs. |
| See more product information |
Benefits
Minimize total cost of ownership with high efficiency eSure rectifiers
Reduce the need for specialized cooling with high temperature operation
Deploy the power system where 120VAC is the only input option
Keep your network power source secure with encrypted controller communication
Extend the life of your batteries with the available battery management tools
Achieve energy savings with ECO mode, even at low loads
Have peace of mind with this UL and NEBS power system
Minimize installation time and drive planned network conformity with custom configuration files
Reduce your off-grid generator runtime with solar / hybrid input
Optimize your battery capacity with priority and non priority load shedding
Solar / hybrid capability – reduces grid dependency
Features
High efficiency – 96.2% efficient eSure rectifiers
Wide operating temperature range – rectifiers function at -40 °C to +80 °C (up to +65 °C without de-rating)
Selectable AC input - 120VAC, 208 to 240 VAC
Supports Ethernet, SNMP V2 & SNMP V3, ModBus and RS485 communication interfaces
Battery management capability
ECO energy savings mode
NEBS Level 3 compliance and UL Listed
Custom configuration file capability
Solar / hybrid capability
Up to two disconnect levels (LVD)
